New Dimension In Network Monitoring

R&M makes the monitoring system of their automated infrastructure management system “R&MinteliPhy” available for any number of ports, display for alarms and instructions in every network cabinet

R&M, the globally active Swiss developer and provider of cabling systems for high-end, powerful network unnamed (65)infrastructures, is expanding the innovative automated infrastructure management system R&MinteliPhy. The central component of the monitoring system, the analyzer, can be upgraded to include additional displays. Thanks to these additional displays, it is now possible to control even more plug connections from an R&MinteliPhy analyzer, making the previous limit of 2000 ports redundant. The expansion means that R&MinteliPhy uses fewer IP addresses than before, allowing the system itself to monitor large data networks.

“The additional displays enable alarm messages and instructions to be displayed in each network cabinet, irrespective of whether they are fitted with an analyzer or not,” says Mr Reinhard Burkert, Product Manager at R&M. “Cabling faults can therefore be localized even faster. Technicians receive information about patching the patch cable exactly where it is needed.” Previously, information could only be displayed in the cabinet in which the analyzer itself was installed.

The R&MinteliPhy analyzer is a component for 19″ cabinets. The device has a rack height unit (1U) and the consumption is 1.8 watts. It monitors the operating status of all assigned ports and sends real-time monitoring data to the R&MinteliPhy server. The analyzer displays error messages and patching instructions. With the new additional display, this information is also available in other network cabinets controlled by the same analyzer.

R&MinteliPhy is a system for automated infrastructure management (AIM) in Data Centers and local data networks. Every link can be monitored continually. A central server records the cabling status from a distance and at remote locations too. Its functions include the management, analysis, and planning of the cabling. This also allows the layout of networks, distributors, computer rooms, or company networks to be visualized and then combined with building plans or geographical site information. R&MinteliPhy automatically generates connection plans if new computers are integrated into the network or plug connections are changed. Unused patch panels and free active device ports can be detected immediately. This information improves the way in which the infrastructure is used, thereby increasing the profitability of the network or Data Center. R&MinteliPhy supports the planning of work procedures. Parts lists for cabling or for network expansion can also be generated automatically, as can work orders for installers or cable labels according to a predefined labeling scheme.

Information on the automated infrastructure management system R&MinteliPhy is available at
