element14 launches BitScope Micro for Raspberry Pi

element14_logo_It Voice  Farnell element14 has partnered  with BitScope Designs to  manufacture and distribute  BitScope Micro, a full feature dual channel digital oscilloscope for Raspberry Pi.

BitScope Micro is also an eight channel logic analyser, waveform generator, clock generator and spectrum analyser all packaged in one low cost lightweight water resistant test probe.

BitScope Micro and Raspberry Pi

BitScope Micro captures digital signals at up to 40 MSps and has a 20 MHz analogue bandwidth. The software supports frame rates beyond 20 Hz and includes a digital phosphor display. It is fully user programmable and downloads are freely available for Raspberry Pi, Linux, Windows and Macintosh.

BitScope Micro and Raspberry Pi 2

BitScope Micro includes 10 mixed signal test clips, a USB cable and input terminators. It uses an industry standard IDC-10 connector for signal I/O. It offers programmable switching levels on two of the logic channels and impedance sensing, multiple ranges and a “macro mode” resolution of 12 bits on both analogue channels. It has standard oscilloscope input impedance (1M/10pF) so BNC adapters can be used to connect regular oscilloscope probes.

Chris Godfrey, Global Product Director Test & Tools at Farnell element14, said: “There has long been a requirement in the market for an entry level oscilloscope to support the maker community and Raspberry Pi specifically. This low cost model from BitScope has all the functionality required for a plug and play oscilloscope.”

Eben Upton, CEO at Raspberry Pi, said: “BitScope Micro is one of the most impressive add-ons for Raspberry Pi we’ve seen. The BitScope team have done a terrific job to optimize their software for Raspberry Pi including the new Model B+.”

Priced at $149, BitScope Micro is available from Farnell element14 in Europe and CPC in the UK, Newark element14 and MCM in North American and element14 in APAC.

A webinar with the Managing Director of the company, Bruce Tulloch, takes place on 29th October 2014 at 3pm BST, more details, and to register, can be found here.
